STMDRAGON STM-1478 Automatic CNC Edge Cutting Saw Machine for Plywood

STMDRAGON STM-1478 is an automatic CNC edge cutting saw designed for plywood production and wood-based panel processing. With PLC control, adjustable sawing speed up to 30 m/min, automatic plate arrangement and stacking, and a maximum board thickness of 60 mm, it is designed for precise and efficient four-edge trimming.

ConfigurationCustom
Working sizeOn request
ControlPLC
ExportFOB / CIF
Request a Quote →
Factory VerifiedExport readyAfter-Sales Support
Technical specifications

Technical specifications: STMDRAGON STM-1478 Automatic CNC Edge Cutting Saw Machine for Plywood

ModelSTM-1478
Machine TypeAutomatic CNC Edge Cutting Saw
Main ApplicationPlywood production and wood-based panel processing
Finished Product4 × 8 ft plywood
Panel Size1220 × 2440 mm (approx. 48.03 × 96.06 in)
Maximum Board Thickness60 mm (approx. 2.36 in)
Sawing Speed0–30 m/min
Control SystemPLC
Working MethodCNC Automatic
Saw Guide Rail 130 mm six-edge guide rail
Saw Guide Rail 2Ø30 mm cylindrical guide rail
Automatic ArrangementOne set of fence-type automatic plate arrangement and stacking
Main Power44.5 kW
Voltage380 V
CertificationCE / ISO 9001
Machine Weight1,200 kg (approx. 2,646 lb)
ColorCustomer's demand
After-Sales ServiceOnline support
Warranty1 Year
Shipping7–30 Days according to the supplied information
Applications

Applications: STMDRAGON STM-1478 Automatic CNC Edge Cutting Saw Machine for Plywood

STMDRAGON STM-1478 Automatic CNC Edge Cutting Saw is designed for plywood production lines and wood-based panel processing. The machine uses PLC automatic control and is designed to perform efficient four-edge trimming with reduced manual labor.

The machine supports 4 × 8 ft plywood panels (1220 × 2440 mm) and can process boards up to 60 mm maximum thickness. Its sawing speed is adjustable from 0–30 m/min, while the automatic plate arrangement and stacking system helps improve production efficiency.

Key Product Details:

  1. Model: STM-1478
  2. Machine Type: Automatic CNC Edge Cutting Saw
  3. Main Application: Plywood production and wood-based panel processing
  4. Finished Product: 4 × 8 ft plywood
  5. Panel Size: 1220 × 2440 mm (approx. 48.03 × 96.06 in)
  6. Maximum Board Thickness: 60 mm (approx. 2.36 in)
  7. Sawing Speed: 0–30 m/min
  8. Control System: PLC
  9. Working Method: CNC Automatic
  10. Saw Guide Rail 1: 30 mm six-edge guide rail
  11. Saw Guide Rail 2: Ø30 mm cylindrical guide rail
  12. Automatic Arrangement: One set of fence-type automatic plate arrangement and stacking
  13. Main Power: 44.5 kW
  14. Voltage: 380 V
  15. Certification: CE / ISO 9001
  16. Machine Weight: 1,200 kg (approx. 2,646 lb)
  17. Color: Customer’s demand
  18. After-Sales Service: Online support
  19. Warranty: 1 Year
  20. Shipping: 7–30 Days according to the supplied information

The machine is designed to improve cutting precision, production efficiency and labor utilization compared with conventional manual sawing methods. The manufacturer states that operation can be handled with approximately 2 workers, depending on the production setup.

Accuracy:

  1. Sawboard diagonal error: less than 1 mm
  2. Saw plate straightness error: less than 1 mm

Tell us your material, size and output target. STMDRAGON will recommend the suitable configuration.

Product details

Additional information

Weight 1700 kg
Dimensions 100 × 900 × 75 cm
Model

STM-1478

Machine Type

Automatic CNC Edge Cutting Saw

Main Application

Plywood production and wood-based panel processing

Finished Product

4 × 8 ft plywood

Panel Size

1220 × 2440 mm (approx. 48.03 × 96.06 in)

Maximum Board Thickness

60 mm (approx. 2.36 in)

Sawing Speed

0–30 m/min

Control System

PLC

Working Method

CNC Automatic

Saw Guide Rail 1

30 mm six-edge guide rail

Saw Guide Rail 2

Ø30 mm cylindrical guide rail

Automatic Arrangement

One set of fence-type automatic plate arrangement and stacking

Main Power

44.5 kW

Voltage

380 V

Certification

CE / ISO 9001

Machine Weight

1,200 kg (approx. 2,646 lb)

Color

Customer's demand

After-Sales Service

Online support

Warranty

1 Year

Shipping

7–30 Days according to the supplied information

Request a quote

Request a quote for STMDRAGON STM-1478 Automatic CNC Edge Cutting Saw Machine for Plywood.

Send your production requirement, electrical standard and destination port. We will reply with the suitable configuration and a current quotation.

Custom configuration
Export documents
Installation support
Spare parts available
Technical, ordering & delivery FAQ

Questions about STMDRAGON STM-1478 Automatic CNC Edge Cutting Saw Machine for Plywood

Clear answers before you request your tailored machine proposal.

Can I get a price for STMDRAGON STM-1478 Automatic CNC Edge Cutting Saw Machine for Plywood?

Yes. Send STMDRAGON your required configuration, capacity, working size, electrical standard and destination port. We will prepare a current quotation.

Why is the price not shown as one fixed number?

Industrial machines are configured for each project. The final price can depend on capacity, automation, electrical components, optional equipment, packing and shipping terms.

Can the machine be customized?

Yes. We can discuss working size, output, control system, safety options, feeding and discharge equipment, and other configuration requirements.

What power supply can you provide?

The electrical standard can be prepared for the destination country. Share the required voltage, frequency and phase in your enquiry.

Can I request Siemens, Schneider or other electrical components?

Preferred electrical brands can be discussed and confirmed in the final technical proposal.

Is the machine suitable for my material?

Tell us the material type, thickness, dimensions and target output. STMDRAGON will recommend the suitable configuration.

What information should I send for a quotation?

Please send the product name, capacity target, working size, material, electrical standard, destination country or port, and any required options.

What is the usual warranty?

Warranty terms are confirmed in the final quotation. A 12-month warranty is commonly offered according to the agreed equipment scope.

Are spare parts available?

Yes. Recommended spare parts can be supplied with the machine or arranged later according to the final order.

Can you provide operation manuals?

English technical documents can be included according to the agreed machine scope.

Can I inspect the machine before shipment?

Yes. Factory inspection, video testing or a third-party inspection can be arranged before shipment.

Do you arrange FOB or CIF shipping?

Our quotations can be prepared on FOB China port terms. CIF shipping to your destination port is available on request.

How is the machine packed?

Packing is selected according to machine size, transport method and destination. Export packing details are confirmed before shipment.

What is the production lead time?

Lead time depends on the configuration and factory schedule. The confirmed production period appears in the final quotation.

Do you provide installation support?

Installation, commissioning and remote technical support can be discussed according to the project and destination.

Can STMDRAGON help with import documents?

We can coordinate the commercial invoice, packing list and normal export documentation needed for the agreed shipment.

Can I buy one set first?

Yes. Most machines can be quoted as one set, subject to the final configuration and factory terms.

How do I know the machine model is right for me?

Send your production target and space details. Our team will compare suitable models and configurations before you order.

Can you support customers after delivery?

STMDRAGON provides after-sales coordination, technical follow-up and spare-parts support according to the agreed order scope.

How do I contact STMDRAGON now?

Use the Request a Quote form below, contact us by WhatsApp, or visit the Contact page with your project details.
