STMDRAGON STM-1593 Automatic CNC Plywood Edge Cutting Saw Machine

STMDRAGON STM-1593 is an automatic CNC edge cutting saw designed for plywood production and wood-based panel processing. It provides automatic four-edge trimming, panel arrangement and stacking with PLC control, adjustable sawing speed up to 30 m/min, and supports plywood up to 60 mm thick.

ConfigurationCustom
Working sizeOn request
ControlPLC-controlled
ExportFOB / CIF
Request a Quote →
Factory VerifiedExport readyAfter-Sales Support
Technical specifications

Technical specifications: STMDRAGON STM-1593 Automatic CNC Plywood Edge Cutting Saw Machine

ModelSTM-1593
Machine TypeAutomatic CNC Edge Cutting Saw
Main ApplicationPlywood production and wood-based panel processing
Working MethodCNC Automatic
ControlPLC-controlled
Power44.5 kW
Voltage380V
Maximum Saw Board Thickness60 mm
Sawing Speed0–30 m/min
Finished Product4 × 8 ft plywood
Panel ArrangementAutomatic fence-type arrangement and stacking
First Saw Guide Rail30 mm six-edge guide rail
Second Saw Guide RailØ30 cylindrical guide rail
Diagonal ErrorLess than 1 mm
Straightness ErrorLess than 1 mm
Machine Weight1,200 kg / approximately 2,646 lbs
CertificationCE, ISO 9001
Warranty1 Year
Shipping7–30 Days according to the supplied information
After-Sales ServiceOnline Support
Applications

Applications: STMDRAGON STM-1593 Automatic CNC Plywood Edge Cutting Saw Machine

The STMDRAGON STM-1593 Automatic CNC Plywood Edge Cutting Saw Machine is designed for efficient four-edge trimming of plywood and wood-based panels in production environments. The machine uses PLC automatic control and can perform continuous sawing without requiring the saw blades to stop during normal cutting operations.

With a 44.5 kW power configuration, adjustable sawing speed of 0–30 m/min, and support for plywood up to 60 mm maximum thickness, the machine is suitable for high-volume plywood production. The finished panel size is designed around 4 × 8 ft plywood, while the specified beveled edge panel length is up to 250 mm.

Key Product Details:

  1. Model: STM-1593
  2. Machine Type: Automatic CNC Edge Cutting Saw
  3. Main Application: Plywood production and wood-based panel processing
  4. Working Method: CNC Automatic
  5. Control: PLC-controlled
  6. Power: 44.5 kW
  7. Voltage: 380V
  8. Maximum Saw Board Thickness: 60 mm
  9. Sawing Speed: 0–30 m/min
  10. Finished Product: 4 × 8 ft plywood
  11. Panel Arrangement: Automatic fence-type arrangement and stacking
  12. First Saw Guide Rail: 30 mm six-edge guide rail
  13. Second Saw Guide Rail: Ø30 cylindrical guide rail
  14. Diagonal Error: Less than 1 mm
  15. Straightness Error: Less than 1 mm
  16. Machine Weight: 1,200 kg / approximately 2,646 lbs
  17. Certification: CE, ISO 9001
  18. Warranty: 1 Year
  19. Shipping: 7–30 Days according to the supplied information
  20. After-Sales Service: Online Support

The automatic panel arrangement and stacking system can help reduce manual handling requirements and improve production efficiency. The manufacturer states that the machine can operate with approximately 2 workers, depending on the production setup.

Tell us your material, size and output target. STMDRAGON will recommend the suitable configuration.

Product details

Additional information

Weight 1455 kg
Dimensions 75 × 90 × 17 cm
Model

STM-1593

Machine Type

Automatic CNC Edge Cutting Saw

Main Application

Plywood production and wood-based panel processing

Working Method

CNC Automatic

Control

PLC-controlled

Power

44.5 kW

Voltage

380V

Maximum Saw Board Thickness

60 mm

Sawing Speed

0–30 m/min

Finished Product

4 × 8 ft plywood

Panel Arrangement

Automatic fence-type arrangement and stacking

First Saw Guide Rail

30 mm six-edge guide rail

Second Saw Guide Rail

Ø30 cylindrical guide rail

Diagonal Error

Less than 1 mm

Straightness Error

Less than 1 mm

Machine Weight

1,200 kg / approximately 2,646 lbs

Certification

CE, ISO 9001

Warranty

1 Year

Shipping

7–30 Days according to the supplied information

After-Sales Service

Online Support
